Union Bonnet Gate Valve, Bronze C83600, CL 300 LB, 2 Inch

Home/Products/Gate Valves/Union Bonnet Gate Valve, Bronze C83600, CL 300 LB, 2 Inch
Union Bonnet Gate Valve, Bronze C83600, CL 300 LB, 2 Inch

Key Specifications / Features

Model No. : 1876037
As a leading supplier of ASTM B62 C83600 bronze gate valves from China, we offer valves designed to MSS SP-80 standards. Our 2-inch (DN50) gate valves feature a union bonnet for easy maintenance, a Class 300 LB pressure rating, and threaded connections for secure installation. With a durable construction and handwheel operation, these valves provide smooth, reliable control in demanding industrial environments. Built for long-lasting performance, they ensure efficient flow regulation and are ideal for a wide range of applications.

Detail Information

Rising Stem Bronze Gate Valve, 2 IN/DN50, 300 LB, MSS SP-80, Standard Bore.

Valve Description:

1876037 Gate Valve
Bore Type: Standard Bore
Design Standard: MSS SP-80
Nominal Size: 2 Inch, DN50
Nominal Class: Class 300 LB, PN50
Body Material: ASTM B62 C83600
Operation: Handwheel
Face to Face: Manufacturer Standard
Test and Inspection: MSS SP-80
Structure: Threaded, Union Bonnet
Trim Material: ASTM B62 C83600
End Connection: Threaded ASME B1.20.1

Key Features:
1. Durable renewable solid wedges.
2. Integral seats for better sealing.
3. High-tensile bronze alloy stems for strength.
4. Shell and seat pressure testing per MSS SP-80 standards.
5. Options for rising and non-rising stems.

Product Range:
Normal Diameter: 1/4, 3/8, 1/2, 3/4, 1, 1-1/2, 2, 2-1/2, 3 IN (DN6 – DN80)
Pressure Range: Class 125 LB - Class 300 LB
Body Material: Bronze ASTM B62
Working Temperature: -20°C to +150°C
Operation: Handwheel
End Connection: Threaded

Drawing for Bronze Gate Valve
