Y Pattern Globe Valve, API 602, 1500 LB, 1/2 IN, ASTM A105N

Home/Products/Globe Valves/Y Pattern Globe Valve, API 602, 1500 LB, 1/2 IN, ASTM A105N
Y Pattern Globe Valve, API 602, 1500 LB, 1/2 IN, ASTM A105N

Key Specifications / Features

Model No. : 1852040
As an API 602 globe valve exporter from China, we offer high-quality valves crafted to ASME B16.34 standards and made from ASTM A105N material. Our valves, rated at Class 1500 LB and sized at 1/2 inch, feature a pressure seal bonnet for exceptional leak protection and durability. Equipped with a butt weld end for secure, permanent installation and a handwheel for precise operation, these valves are designed for demanding high-pressure applications. Rely on our expertise for reliable, top-performance globe valves that meet your industrial needs with precision and strength.

Detail Information

API 602 Y Globe Valve, Pressure Seal Bonnet, 1/2 Inch, 1500 LB, A105N Body, for Power Plant.


Valve Description:
1852040 Globe Valve
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, Pressure Seal Bonnet, Welded Bonnet, Bonnetless
Nominal Size: 1/2 Inch
Nominal Class: 1500 LB
Bore Type: Reduced
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Body Material: ASTM A105N, ASTM A182 F11, ASTM A182 F22, ASTM A182 F316, ASTM A182 F91
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Test and Inspection: API 598


Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service


Product Line
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
Working Temperature: -29°C - +525°C
Operation: Manual or Actuated
End Connection: BW/SW/NPT


Drawing for Globe Valve
