12 Inch Flanged Globe Valve, API 623, BS 1873, B148 C95800

Key Specifications / Features

Model No. : GLV-187305029

We are a leading flanged globe valve manufacturer in China, specializing in high-performance valves built to API 623 and BS 1873 standards. Our 12-inch globe valves are made from durable aluminum bronze ASTM B148 C95800 for both body and trim, offering superior corrosion resistance in marine, offshore, and industrial environments. Designed for Class 300 LB pressure rating, these valves ensure reliable flow control and long service life. Available with flat face (FF) or raised face (RF) flanged ends, they provide flexible installation options to suit various piping systems and demanding applications.


Detail Information

Valve Description:
187305029 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 12 Inch
Nominal Class: 300 LB
Bore Type: Standard Bore
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
