Al-bronze Gate Valves, API 600, B148 C95800, 2-1/2 IN, CL600

Key Specifications / Features

Model No. : 1821202

Cast steel gate valve is designed in accordance with API 600 standards for reliable shut-off performance in demanding industrial applications. This 2-1/2 inch valve features DN65 size, Class 600 LB pressure rating, ASTM B148 C95800 material, bolted bonnet construction, RF flanged ends, and rising stem design for clear position indication and easy operation. It provides excellent corrosion resistance, tight sealing, and durable service life under high-pressure and high-temperature conditions. Widely used in oil, gas, petrochemical, and marine industries. As a leading China API 600 Gate Valve Factory, we ensure high-quality manufacturing and dependable valve solutions.


Detail Information

Valve Description:
1821202 Cast Steel Gate Valve
Design Standard: API 600
Face to Face: ASME B16.10
Sizes: 2-1/2 Inch, DN65
Pressure Rating: Class 600 LB
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM B148 C95800, ASTM A216 WCB, ASTM A995 5A, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC, ASTM A217 C5, ASTM A995 4A, ASTM A217 C12A, ASTM A217 WC9, ASTM A995 6A, ASTM A351 CF8, ASTM A351 CF3, ASTM A216 WCC, ASTM A351 CF3M, ASTM A217 WC6
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55

Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
