Key Specifications / Features

Model No. : SCKV-187306014

We are a reliable Al-bronze check valve provider in China, offering high-performance valves designed in accordance with API 594 standards. Each valve features a sturdy ASTM B148 C95800 aluminum bronze body and trim, delivering outstanding corrosion resistance for seawater and harsh industrial applications. This 26-inch model is rated for Class 150 LB and comes with a secure bolted bonnet for easy maintenance and long-term durability. Available with flat face (FF) or raised face (RF) flanged ends, our check valves ensure tight, leak-free connections to suit various pipeline requirements.



Detail Information

Valve Description:
187306014 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Nominal Size: 26 Inch
Nominal Class: 150 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service


Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
