Key Specifications / Features
Model No. : 1.5G8SLF208
Purchase high-quality API 602 forged gate valves from a trusted provider. Available in 1-1/2 inch size (DN40) and suitable for 800 LB (PN130) applications. Manufactured to ASME B16.34 standards using ASTM A350 LF2 material with ASTM A182 F6A Trim 8. Features include a bolted bonnet, outside screw and yoke design (OS & Y), and a convenient handwheel for operation. Ideal for use in severe service environments.
Categories
Gate Valves
Tags:
1-1/2 Inch Gate Valve
, Class 800 LB Gate Valve
, ASTM A350 LF2 Gate Valve
.
1-1/2 INCH, 800 LB, Forged Gate Valve, API 602, SW, LF2 body and trim 8, Handwheel
Valve Description:
1851031 API 602 Forged Gate Valve 1.5G8SLF208
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1-1/2 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A350 LF2
Trim Material: F6A+STL.6
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
