Key Specifications / Features
Model No. : 1G8SLF208
Get premium quality Forged Steel ASTM A350 LF2 Gate Valve from a reliable supplier. Available in 1 inch size (DN25) with a pressure rating of 800 LB (PN130), meeting API 602 and ASME B16.34 standards. Features include F6A+STL.8 Trim, Handwheel operation, Bolted Bonnet design, and OS & Y configuration. Suitable for various industrial applications.
Categories
Gate Valves
Tags:
1 Inch Gate Valve
, Class 800 LB Gate Valve
, ASTM A350 LF2 Gate Valve
.
1 INCH, 800 LB, Forged Gate Valve, API 602, SW, LF2 body and trim 8, Handwheel
Valve Description:
1851030 API 602 Forged Gate Valve 1G8SLF208
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A350 LF2
Trim Material: F6A+STL.6
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
