API 6D Floating Ball Valve, 3/4 Inch, 1500 LB, SW X NPT

Key Specifications / Features
Model No. : 0.75BB15SNA105N

Introducing our standardized 3/4 inch, 1500 LB Floating Ball Valve with SW X NPT Threaded End. This valve complies with ISO 17292 and features an ASTM A105 body with 316 Trim. It is equipped with an RPTFE seat and operates smoothly with a lever. Discover reliable and efficient valve solutions for your industrial needs.v

Categories Floating Ball Valve

Tags: API 6D Ball Valve , 3/4 Inch Ball Valve , Class 1500 LB Ball Valve .

Detail Information
3/4 inch, 1500 LB, Floating Ball Valve, SW X NPT Threaded End, ISO 17292, ASTM A105 body with 316 Trim, RPTFE seat and lever operation

Valve Description:
1812010 Floating Ball Valve 0.75BB15SNA105N
Design Standard: API 608, ISO 17292, API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 3/4 Inch, DN20
Nominal class: 1500 LB
Bore Type: Reduced Bore
End Connection: SW X NPT
Operation: Lever Lockable
Body Material: ASTM A105
Trim Material: ASTM A182 F316, RPTFE
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: Class 150 - 2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator




Nickname*:
E-mail*:
Rate*:
Comments*:

Next: Three Pieces Floating Ball Valve, 1 Inch, 800 LB, ASTM A105

Previous: API 608 ISO 17292 Floating Ball Valve, 3/4 IN, 800 LB, A105
