This forged F22 wedge gate valve is rated Class 600 with NPS 1 socket weld ends, built to API 602 and ASME B16.34 standards. It features V35 trim, a bolted bonnet, and OS&Y handwheel operation. Made of ASTM A182 F22 chrome-moly alloy steel, it suits high-temperature steam, power, and petrochemical piping. It follows ASME B16.11 end requirements and API 598 testing for reliable tight shutoff under severe high-pressure working conditions.
Product Name: Forged Alloy Steel Gate Valve
Size: NPS 1 (1 Inch), DN25
Pressure Class: Class 600 LB, PN100
Body & Bonnet Material: ASTM A182 F22 (2.25Cr-1Mo Alloy Steel)
Trim Code: V35
End Connection: Socket Weld (SW)
Operation: Handwheel Operated, Bolted Bonnet, OS&Y (Outside Screw and Yoke)
Design Standard: API 602, ASME B16.34
End Standard: ASME B16.11 for Socket Weld Ends
Inspection & Test Standard: API 598
Direction: Flow direction marked by arrow on body
Applicable Service: High-temperature steam, power, petrochemical, high-pressure alloy pipeline service
Type: Wedge Gate Valve
NPS: Nominal Pipe Size
Class 600: ASME pressure rating
ASTM A182 F22: Forged chromium-molybdenum alloy steel for high-temperature pressure parts
V35: Standard valve trim material code for seat, disc, and stem
Socket Weld: Socket welding end connection
OS&Y: Outside Screw and Yoke; the stem threads are outside the valve pressure boundary
API 602: Specification for compact forged steel gate, globe and check valves
ASME B16.34: Valves – Flanged, Threaded, and Welding End
ASME B16.11: Forged Fittings, Socket-Welding and Threaded
API 598: Valve Inspection and Testing
