ASTM A216 WCB Gate Valve, API 600, 48 Inch, ANSI CL 600 LB

Key Specifications / Features

Model No. : 1821105
We manufacture high-quality ASTM A216 WCB carbon steel gate valves in China, designed to meet API 600 standards. Our 48-inch (DN1200) valves are rated for ANSI 600 pressure class and feature an OS&Y configuration with a flexible wedge and pressure seal bonnet (PSB) for enhanced durability and reliable sealing. With RF flanged ends for secure connections, these valves are built for optimal performance in demanding industrial environments. Engineered for precision and longevity, our gate valves offer superior flow control and are ideal for high-pressure applications.

Detail Information

Aluminum Bronze Gate Valve, ASTM A216 WCB Body, API 600, 48 Inch/DN1200, Class 600 LB, OS&Y, RF Flanged.

Valve Description

1821105 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8M, ASTM A351 CF8, ASTM A890 4A, 5A, ASTM B148 C95800.
Nominal Size: 48 Inch, DN1200
Nominal Class: CL 600 LB, PN100
End Connection: RF Flanged
Face to Face: ASME B16.10
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF, RTJ, BW
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
Seat Types: Metal Seat Gate Valve(hard faced), Resilient Gate Valve(rubber seat) Bonnet
