ASTM A350 LF2 Ball Valve, API 6D, Alloy Steel, 3 IN, CL300 LB

Key Specifications / Features

Model No. : 181203014

Our 3-inch Class 300 LB floating ball valve is engineered to meet API 6D and ISO 17292 standards, ensuring reliable performance in demanding flow control applications. Designed with a robust bolted bonnet and a precision-machined soft seat, it delivers excellent sealing and smooth operation. The ASTM A350 LF2 carbon steel body provides exceptional low-temperature toughness, while the F316 stainless steel trim enhances corrosion resistance and durability. Featuring lever operation for easy manual control, this valve is suitable for various industrial pipelines. As a leading alloy steel floating ball valve provider in China, we supply high-quality valves built for long-term service.


Detail Information

Valve Description:
181203014 Floating Ball Valve
Design Standard: ISO 17292, API 608, API 6D
Structure: 2pcs body, Side Entry, Bolted Bonnet, Soft Seat
Sizes: 3 Inch, DN80, 80 mm
Pressure: Class 300 LB, PN50
Bore Type: Full Bore or Reduced Bore
End Connection: RF, RTJ
Operation: Lever
Body Material: ASTM A105N or A350 LF2 or A182 F316, ASTM A216 WCB, ASTM A216 WCC, ASTM A352 LCB, ASTM A352 LCC, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A995 4A, ASTM A995 5A, ASTM A995 6A, ASTM B148 C95800
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55, A105+ENP, LF2+ENP
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: Anti-static, Fire Safe, Anti-Blowout Stem

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 Inch - 6 Inch (DN15 – DN150)
Pressure range: Class 150 LB - 300 LB
End connection: Flanged
Working temperature: -26°C - +210°C
Operation: Manual(lever), Pneumatic Actuator
