Key Specifications / Features

Model No. : 181203013

This forged 2-piece floating ball valve is designed in accordance with ISO 17292, ensuring reliable performance and long-term durability in demanding industrial environments. Featuring a side-entry construction, the valve is built with a corrosion-resistant ASTM A351 CF8M stainless steel body and robust F6A trim, providing excellent strength and wear resistance. With a 2-inch size, Class 300 LB pressure rating, and smooth lever operation, it delivers precise flow control and secure shutoff. Engineered for versatility and efficiency, it is ideal for chemical, petrochemical, and general industrial applications. As a leading 2-piece floating ball valve factory in China, we offer high-quality, dependable valve solutions.



Detail Information

Valve Description:
181203013 Floating Ball Valve
Design Standard: ISO 17292, API 608, API 6D
Structure: 2pcs body, Side Entry, Bolted Bonnet, Soft Seat
Sizes: 2 Inches, DN50, 50 mm
Pressure: Class 300 LB
Bore Type: Full Bore or Reduced Bore
End Connection: RF, RTJ
Operation: Lever
Body Material: ASTM A105N or A350 LF2 or A182 F316, ASTM A216 WCB, ASTM A216 WCC, ASTM A352 LCB, ASTM A352 LCC, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A995 4A, ASTM A995 5A, ASTM A995 6A, ASTM B148 C95800
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55, A105+ENP, LF2+ENP
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: Anti-static, Fire Safe, Anti-Blowout Stem

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 6 Inch (DN15 – DN150)
Pressure range: 150 - 300 LB
End connection: Flanged
Working temperature: -26°C - +210°C
Operation: Manual(lever), Pneumatic Actuator
