Key Specifications / Features

Model No. : 10BS100JF65

Certified Three-Piece Trunnion Mounted Ball Valve Manufacturer: Compliant with API 6D and API 6A Standards, Featuring 10-Inch Size, 10,000 PSI Pressure Rating, Crafted from ASTM A694 F65 Material, Equipped with Side Entry, Bolted Bonnet, Full Bore Design, and RTJ Flanged Connections.


Detail Information

API 6A Trunnion Mounted Ball Valve, API 6D, API 6A, 10 inch, 10000 PSI, RTJ, A694 F65 Body, F6A Trim, PEEK Seat, Gear Operation

Valve Description:
1811043 Trunnion Mounted Ball Valve 10BS100JF65
Design Standard: API 6D, API 6A
Structure: Three pieces body, Side Entry, Bolted Bonnet
Nominal size: 10 Inch
Nominal class: 10000 PSI
Bore Type: Full Bore
End Connection: RTJ Flanged
Operation: Gear
Body Material: ASTM A694 F65
Trim Material: AISI 4140, ASTM A182 F6A, PEEK
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: DBB, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
