Key Specifications / Features
Model No. : 10SPS25J4A
Buy high-quality ASTM A995 4A Swing Check Valve from a leading factory. Our valves are built to meet industry standards such as BS 1868 and API 594. With a size of 10 inches and a Class 2500 LB rating, our valve is suitable for demanding applications. It has a DN250 and PN420 specification, ensuring optimal performance. Featuring a pressure seal bonnet, swing disc, and standard bore, this valve is designed for durability and efficiency. The RTJ end adds stability and reliability to the installation. Shop now for reliable and standardized ASTM A995 4A Swing Check Valves.
Categories
Swing Check Valve
Tags:
ASTM A995 4A Check Valve
, BS 1868 Check Valve
, 10 Inch Check Valve
.
10 Inch 2500 LB Swing Check Valve, Flanged RTJ, BS 1868, A995 4A body and Trim, Pressure Seal Bonnet.
Valve Description:
1841007 Swing Check Valve 10SPS25J4A
Design Standard: BS 1868, API 594
Structure: Pressure Seal Bonnet, Swing type
Nominal size: 10 Inch
Nominal class: 2500 LB
Bore Type: Standard Bore
End Connection: RTJ
Operation: /
Body Material: ASTM A995 4A
Trim Material: ASTM A995 4A
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: /
