Key Specifications / Features
Model No. : 3T1LC958
Discover our top-tier Concentric Butterfly Valve, designed to perfection with specifications including 3-inch diameter, 150 LB rating, DN80 size, PN16 pressure class, compliant with API 609 Category A and EN 593 standards. Crafted from durable Al-bronze ASTM B148 C95800 for both body and disc, featuring EPDM lined seats for optimal performance. Equipped with lug-style connections and a convenient lever for seamless operation.
Categories
Concentric Butterfly Valve
Tags:
API 609 Cat A Butterfly Valve
, EN 593 Butterfly Valve
, Lug Butterfly Valve
.
Concentric Butterfly Valve, 3 inch, 150 LB, PN16, LUG, Al-bronze B148 C95800 body, C95800 Al-Brz Disc, EPDM lined seat, Lever Operation
Valve Description:
1861010 Concentric Butterfly Valve 3T1LC958
Design Standard: API 609 Cat A, EN 593
Structure: Concentric
Nominal size: 3 Inch, DN80
Nominal class: 150 LB, PN16
End Connection: LUG
Operation: Lever Operation
Body Material: ASTM B148 C95800
Trim Material: B148 C95800 disc, EPDM seat
Face to face: API 609
Test and inspection: API 598
Key Features: Anti-corrosive rubber seat, Low torque, Excellent control characteristics, Economical material and installation space, for seawater, offshore, FPSO
Product Range:
Body material: Iron, WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: PN6-PN20
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
