Key Specifications / Features
Model No. : 6B1RC958
Explore high-quality 6-inch ASTM B148 C95800 ball valves manufactured to Class 150 LB and PN20 standards. This API 608-compliant valve features ASTM B150 C63200 trim, a soft seat, and lever operation. Designed with precision, it boasts RF ends for seamless integration. Trust in reliability and performance for your industrial needs.
Categories
Floating Ball Valve
Tags:
API 608 Ball Valve
, 6 Inch Ball Valve
, Class 150 LB Ball Valve
.
Floating Ball Valve, API 608, DN150, 150 LB, RF, ASTM B148 C95800 Body, B150 C63200 Trim, Soft Seat, Lever Operated
Valve Description:
1812044 Floating Ball Valve 6B1RC958
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 6 Inch, DN50
Nominal class: 150 lb, PN16
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Lever Operation
Body Material: ASTM B148 C95800
Trim Material: ASTM B150 C63200, RPTFE/TFM 1600
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device
Product Range:
Body material: AL-BRONZE (ASTM B148 C95800, ASTM B150 C63200)
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: 150 - 300 LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator.
