ASTM B148 C95800 Gate Valve, API 600, 42 IN, BB, OS&Y, FF

Key Specifications / Features

Model no. : GTV-187304020

We are a factory specializing in API 600 gate valves, offering high-performance solutions with an aluminum bronze ASTM B148 C95800 body and trim for superior corrosion resistance. Designed for reliability in demanding environments, these valves come in a large 42-inch size with a Class 150 LB pressure rating. They feature a bolted bonnet for secure sealing, an outside screw and yoke (OS\&Y) design for easy operation, and are available with flat face (FF) or raised face (RF) flanged ends. Operated by handwheel or gear, they ensure smooth and dependable flow control.


Detail Information

Valve Description:
187304020 Aluminum Bronze Gate Valve, Flexible Wedge.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 42 Inch
Nominal Class: Class 150 LB, Class 300 LB
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
