ASTM B148 C95800 Swing Check Valve, API 6D, BS 1868, 36 Inch

Key Specifications / Features

Model No. : SCKV-187306018

We are a trusted swing check valve plant in China, producing high-quality valves designed to meet API 6D and BS 1868 standards for dependable backflow prevention. Our swing check valves feature a robust ASTM B148 C95800 aluminum bronze body and trim, offering excellent corrosion resistance for seawater and harsh industrial environments. This 36-inch model is rated for Class 150 LB and includes a secure bolted bonnet for reliable sealing and easy maintenance. Available with flat face (FF) or raised face (RF) flanged ends, our valves ensure tight, leak-free pipeline connections.

Detail Information

Valve Description:
187306018 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Nominal Size: 36 Inch
Nominal Class: 150 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
