Key Specifications / Features
Model No. : 3G15BA10505
We Provide Bolted Bonnet Gate Valves, Solid Wedge, Forged Body, API 600, ASTM A105, 3 Inch, 1500 LB, DN80, PN250, Butt Weld, and Non-rising Handwheel.
Bolted Bonnet Forged Gate Valve, API 600, A105, 3IN, 1500LB
Detail Information
Product Item: Wedge Gate Valve
Model No.: 3G15BA10505
Design Standard: API 600
Structure: Bolted Bonnet, Forged Body
Nominal size: 3 Inch
Nominal class: 1500 LB
Bore Type: Standard Bore
End Connection: BW (Butt Weld)
Operation: Handwheel
Body Material: ASTM A105
Trim Material: 1Cr13+STL, No.5
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Solid Wedge, OS&Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN600)
Pressure range: 900 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +425℃
Operation: Handwheel, Gear, Motor Actuator
