Side Entry Floating Ball Valve, ASTM A351 CF3, 2 IN, 150 LB

Key Specifications / Features

Model No. : 181203005

This 2-inch (DN50) side entry floating ball valve is expertly crafted from ASTM A351 CF3 stainless steel, ensuring durability and corrosion resistance. Designed with a 2-piece body, it complies with ISO 17292, API 608, and API 6D standards for reliable performance in industrial applications. Rated at Class 150 LB, the valve features lever operation for precise and effortless flow control. Its side-entry design allows easy maintenance without removing the entire pipeline. As a leading floating ball valve factory in China, we provide high-quality valves built for longevity, smooth operation, and superior sealing in demanding environments.


Detail Information

Valve Description:
181203005 Floating Ball Valve
Design Standard: ISO 17292, API 608, API 6D
Structure: 2pcs body, Side Entry, Bolted Bonnet, Soft Seat
Sizes: 2 Inch, DN50, 50 mm
Pressure Rating: Class 150 LB, PN20
Bore Type: Full Bore or Reduced Bore
End Connection: RF, RTJ
Operation: Lever
Body Material: ASTM A105N or A350 LF2 or A182 F316, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, A995 4A, A995 5A, A995 6A, C95800
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55, A105+ENP, LF2+ENP
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: Anti-static, Fire Safe, Anti-Blowout Stem

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 Inch - 6 Inch (DN15 – DN150)
Pressure range: Class 150 LB - 300 LB
End connection: Flanged
Working temperature: -26°C - +210°C
Operation: Manual(lever), Pneumatic Actuator
