Stainless Steel Trunnion Ball Valve, DBB, 3PC, 4 IN, CL1500

Key Specifications / Features

Model No. : 181101016

Trunnion-mounted ball valve fitted with pneumatic spring return actuator and manual handwheel backup. This Class 1500 full-bore DBB valve in NPS4 DN100 is constructed from ASTM A182 F316 forged stainless steel, featuring a three-piece bolted forged body. The spring-return pneumatic actuator enables fail-safe shutoff upon air loss, with manual override for emergency operation. It is equipped with body cavity relief and a seat sealant injection port for inline maintenance. Suited for oil, gas, and chemical pipelines, it provides reliable tight sealing and automatic safety isolation under high-pressure, corrosive service.

Detail Information

Valve name: Trunnion-mounted ball valve
Body structure: 3-piece forged bolted body
Flow path: Full bore
Seat design: Double block and bleed (DBB)
Design standard: API 6D, ASME B16.34
Operation: Pneumatic spring-return actuator with manual handwheel
Pressure class: Class 1500 LB
Nominal size: NPS 4 (DN100)
Body material: ASTM A182 F316 stainless steel
End connection: Flanged end
Feature: Body cavity relief, seat sealant injection port
Flange dimension: ASME B16.5
Face-to-face length: Compliant with API 6D
Available body materials: ASTM A105, ASTM A105N, ASTM A182 F304, ASTM A182 F316
Ball material choices: ASTM A182 F304, ASTM A182 F316, hardfacing overlay optional
Seat material choices: PTFE, RPTFE, PEEK, Devlon, metal-to-metal
Stem material: ASTM A182 F316
Bolting hardware: ASTM A193 B7 studs and ASTM A194 2H nuts
Operating temperature: -29°C to +180°C, cryogenic version available
Applicable media: Natural gas, crude oil, refined fuels, corrosive petrochemical fluids
Inspection and test: API 6D hydrostatic and functional test
Surface treatment: Epoxy coating for carbon steel; machined bare surface for stainless steel
