10 Inch Gate Valves, Aluminum Bronze, C95800, 300 LB, BB, FF

Key Specifications / Features

Model No. : GTV-187304028

Engineered to API 600 standards, this 10-inch (DN250) gate valve features a durable body and trim crafted from ASTM B148 C95800 aluminum bronze, offering excellent corrosion resistance. With a Class 300 LB pressure rating, it includes a bolted bonnet for reliable sealing and long-lasting performance. Available with flat face (FF) or raised face (RF) flanged ends, it ensures compatibility with a wide range of piping systems. Ideal for marine, offshore, and other harsh environments. Manufactured by a leading aluminum bronze gate valve supplier in China.


Detail Information

Valve Description:
187304028 Aluminum Bronze Gate Valve, OS&Y.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 10 Inch, DN250
Nominal Class: Class 300 LB
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
