6 Inch Al-bronze Gate Valve, API 600, B148 C95800, CL300 LB

Name: 6 Inch Al-bronze Gate Valve, API 600, B148 C95800, CL300 LB
SKU: gtv-187304026
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : GTV-187304026

This 6-inch (DN150) aluminum bronze gate valve is designed in accordance with API 600 standards and constructed from durable ASTM B148 C95800 material. With a pressure rating of Class 300 LB, it comes with either flat face (FF) or raised face (RF) flanged ends for flexible installation. The valve ensures dependable shutoff and is operated by handwheel or optional gear for smooth control. Built for harsh environments, it offers excellent corrosion resistance and long-term performance. Produced by a leading aluminum bronze gate valve manufacturer in China.

Request a quote

Tags:

6 Inch Gate Valve

Al-bronze Gate Valve

API 600 Gate Valve

Detail Information

Valve Description:
187304026 Aluminum Bronze Gate Valve.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 6 Inch, DN150
Nominal Class: Class 300 LB
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Bore Type: Standard Bore(API 600)
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
