8 Inch Globe Valves, ASTM B148 C95800, CL300 LB, RF Flanged

Key Specifications / Features

Model No. : GLV-187305027

We are a specialized globe valve factory in China, producing high-quality valves that meet the BS 1873 and API 623 standards. Our 8-inch globe valves feature a corrosion-resistant ASTM B148 C95800 aluminum bronze body and trim, making them ideal for demanding environments such as marine and offshore applications. Rated for Class 300 LB, these valves come with RF flanged ends for secure and reliable installation. Designed with a standard bore, they ensure smooth and efficient flow control. Engineered for durability and performance, our valves deliver long-term reliability in critical service conditions.



Detail Information

Valve Description:
187305027 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM B148 C95800
Nominal Size: 8 Inch
Nominal Class: 300 LB
Bore Type: Standard Bore
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
