API 623 Bolted Bonnet Globe Valve, C95800, 8 IN, CL150, OS&Y

Key Specifications / Features

Model No. : GLV-187305006

We are a trusted supplier of bolted bonnet globe valves, designed in compliance with API 623 and BS 1873 standards for dependable flow control. This 8-inch, Class 150 LB valve features a rugged body and trim made from corrosion-resistant aluminum bronze ASTM B148 C95800, ideal for marine and corrosive environments. The OS&Y (outside screw and yoke) design ensures easy maintenance and reliable sealing performance. With FF or RF flanged ends available, this valve offers installation flexibility and is suitable for a wide range of industrial applications requiring durability and long-term service.


Detail Information

Valve Description:
187305006 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Nominal Size: 8 Inch, DN200
Nominal Class: 150 LB, PN20
Bore Type: Standard Bore
Structure: Bolted Bonnet/Pressure Seal Bonnet
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: FF or RF Flanged
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
