Al-bronze Globe Valve, BS 1873, API 623, 42 IN, CL150, RF

Name: Al-bronze Globe Valve, BS 1873, API 623, 42 IN, CL150, RF
SKU: glv-187305020
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : GLV-187305020

We are a reputable aluminum bronze globe valve supplier in China, offering high-quality valves built to BS 1873 and API 623 standards. Our 42-inch globe valves feature a durable ASTM B148 C95800 body, providing exceptional corrosion resistance for marine and harsh industrial environments. With a Class 150 LB pressure rating, these valves include RF flanged ends for secure installation, a rising stem and OS&Y design for safe and visible operation, and a bolted bonnet for easy maintenance. Designed for reliability and longevity, they ensure precise flow control in critical service applications.

Request a quote

Tags:

Al-bronze Globe Valve

BS 1873 Globe Valve

API 623 Globe Valve

Detail Information

Valve Description:
187305020 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Nominal Size: 42 Inch
Nominal Class: 150 LB
Bore Type: Standard Bore
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y configuration for safe operation, rising stem with non-rising handwheel, screwed-in back seat for added durability, and a flexible wedge for tight sealing. Designed with a low emission structure and constructed from corrosion-resistant aluminum bronze, this valve is ideal for seawater and other corrosive service applications.

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
