Aluminum Bronze Check Valve, C95800, API 6D, 36 IN, CL300 LB

Name: Aluminum Bronze Check Valve, C95800, API 6D, 36 IN, CL300 LB
SKU: ckv-187306039
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : CKV-187306039

We are a reputable aluminum bronze check valve manufacturer in China, supplying high-quality valves engineered to meet API 6D, BS 1868, and API 594 standards. Our check valves are built with a durable bolted bonnet and crafted from premium ASTM B148 C95800 aluminum bronze, ensuring excellent corrosion resistance and long service life in demanding applications. Available in large sizes up to 36 inches and rated for Class 300 LB, these valves provide reliable backflow prevention and efficient flow control. Options for flat face (FF) or raised face (RF) flanged ends offer secure connections and easy installation.

Request a quote

Tags:

Aluminum bronze Check Valve

ASTM B148 C95800 Check Valve

API 6D Check Valve

Detail Information

Valve Description:
187306039 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Body Material: ASTM B148 C95800
Nominal Size: 36 Inch
Nominal Class: 300 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Al-bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
