API 6D Ball Valve, AISI 4130/F65, 6-1/8 Inch, 10000 PSI, RTJ

Key Specifications / Features

Model No. : BV-181105095

As a leading API 6D ball valve manufacturer in China, we specialize in delivering high-pressure solutions engineered for demanding oil and gas operations. Our ball valves are constructed with durable AISI 4130 or ASTM A694 F65 bodies to provide exceptional strength and long-term performance. Each valve is equipped with high-grade 17-4PH or Inconel trim to ensure outstanding resistance to wear and corrosion. Built in a 6-1/8 inch size and rated for 10,000 PSI, these metal-seated designs perform reliably in extreme environments. Customers can choose RTJ or butt-weld ends, complemented by an ISO 5211 mounting pad for seamless actuator installation.

Detail Information

Valve Description:
181105095 Compact Ball Valve
Design Standard: API 6A/API 6D
Structure: 1PC Body
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2000-15000 PSI
Body Material: AISI 4130/ASTM A694 F60/A694 F65
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Operation: Lever/Gear/Bare Shaft
Bore Type: Full Bore or Reduced Bore
End Connection: RTJ, BW, and Hub
Seat Insert: POM/PEEK or hard faced
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A/API 6D

Key Features:
Compact design with short face-to-face and low weight
Low torque
Easy for maintenance
Removable seat retainer to reduce torque, and it is easy to repair

• Material Class: AA, BB, CC, DD, EE, FF, HH
• Temperature Class: L, N, P, S, T, U, V, X, Y
• Specification: PSL1 - PSL3G
• Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2000PSI - 15000PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
