ASTM A105 Pneumatic Trunnion Ball Valve, 12 Inch, 600 LB

Home/Products/Ball Valves/Trunnion Mounted Ball Valve/ASTM A105 Pneumatic Trunnion Ball Valve, 12 Inch, 600 LB
ASTM A105 Pneumatic Trunnion Ball Valve, 12 Inch, 600 LB

Key Specifications / Features

Model No. : 181101001
This pneumatic trunnion-mounted ball valve is engineered for reliable on-off service in oil, gas, and petrochemical pipelines. It adopts an A105 carbon steel body, F304 ball, and PTFE seat, complying with the ASME B16.34 design standard and API 598 test specification. This unit is sized at 12 inches with a Class 600 pressure rating and ASME B16.5 flanged ends. Equipped with a carbon steel spring-return pneumatic actuator, it features an anti-blowout stem, double-piston effect seat, and fire-safe construction for stable long-term operation.

Detail Information

Pneumatic Trunnion-Mounted Ball Valve

Valve type: Trunnion-mounted ball valve
Body material: ASTM A105
Ball material: ASTM A182 F304
Seat material: PTFE
Nominal pressure: Class 600 LB, PN100, Class 150 - 2500 LB
Nominal size: 12 Inch, DN300, 2 - 48 Inch
End connection: Flanged, ASME B16.5
Design standard: ASME B16.34
Inspection and test: API 598
Actuator type: Pneumatic spring return actuator
Actuator material: Carbon steel
Operation: Pneumatic on-off operation
Features: Anti-blowout stem, double-piston effect seat, fire-safe design, ISO 5211 mounting pad
Application: Oil, gas, petrochemical, power, pipeline transmission
