ASTM B148 C95800 Swing Check Valve, BS 1868, 2-1/2 IN, CL150

Name: ASTM B148 C95800 Swing Check Valve, BS 1868, 2-1/2 IN, CL150
SKU: ckv-187306002
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : CKV-187306002

As a trusted swing check valve supplier, we offer a 2-1/2 inch valve designed to BS 1868 standards and built with a corrosion-resistant ASTM B148 C95800 aluminum bronze body and trim. Rated for Class 150 LB, it features a bolted bonnet for secure maintenance and is available with either flat face (FF) or raised face (RF) flanged ends to suit various installation needs. Engineered for durability and dependable backflow prevention, this valve is ideal for marine, offshore, and industrial applications requiring reliable performance in corrosive environments.

Request a quote

Tags:

ASTM B148 C95800 Check Valve

BS 1868 Check Valve

2-1/2 Inch Check Valve

Detail Information

Valve Description:
187306002 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Nominal Size: 2-1/2 Inch
Nominal Class: 150 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted bonnet for secure sealing, optional full opening design for maximum flow, operation lever available for manual control, and corrosion-resistant aluminum bronze construction ideal for seawater service.

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)

Next: API 594 Al-bronze Check Valve, C95800, 3 Inch, CL150 LB, RF

Previous: Aluminium Bronze Check Valve, API 6D, 2 Inch, CL150, RF Ends
