Aluminum Bronze Globe Valve, BS 1873, C95800, 28 Inches, PSB

Name: Aluminum Bronze Globe Valve, BS 1873, C95800, 28 Inches, PSB
SKU: glv-187305015
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : GLV-187305015

We are a leading manufacturer of aluminum bronze globe valves, engineered to BS 1873 design standards for high performance in corrosive and marine environments. Our 28-inch globe valves feature a robust ASTM B148 C95800 body and trim, offering exceptional resistance to seawater and harsh chemicals. With a Class 150 LB pressure rating, these valves are equipped with a pressure seal bonnet for enhanced sealing under high-pressure conditions and RF flanged ends for secure installation. Designed for durability, reliability, and efficient flow control, our valves are ideal for critical industrial applications.

Request a quote

Tags:

Aluminum bronze Globe Valve

BS 1873 Globe Valve

ASTM B148 C95800 Globe Valve

Detail Information

Valve Description:
187305015 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Body Material: ASTM B148 C95800
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 28 Inch
Nominal Class: 150 LB
Bore Type: Standard Bore
Operation: Handwheel/Gear
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: FF or RF Flanged

Key Features: OS&Y design, screwed-in back seat, rising stem with non-rising handwheel, flexible wedge for tight sealing, low emission construction, and durable aluminum bronze material ideal for seawater service.

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
