Non-rising Stem Gate Valves, API 600, Al-bronze, 18 IN, PSB

Key Specifications / Features

Model No. : GTV-187304032

We are a factory specializing in non-rising stem gate valves, designed in accordance with API 600 standards. This 18-inch (DN450) valve is crafted from corrosion-resistant aluminum bronze ASTM B148 C95800, ensuring long-term durability in harsh environments. Rated for Class 300 LB, it features a flexible wedge for improved sealing and adaptability under pressure variations. The valve is available with either flat face (FF) or raised face (RF) flanged ends, providing versatile installation options. Ideal for marine, offshore, and corrosive media applications, our valve delivers reliable performance and robust construction.


Detail Information

Valve Description:
187304032 Aluminum Bronze Gate Valve, OS&Y, Flexible Wedge.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 18 Inch, DN450
Nominal Class: Class 300 LB
Bore Type: Standard Bore(API 600)
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service


Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
